ib_interpolateLines.m File Reference

Interpolate lines between the slices. More...

Functions
function img =	ib_interpolateLines (img, max_pnts, lineWidth)
	Interpolate lines between the slices. More...
function contour =	ibinterpolateLines>interp_points (contour1, contour2, slice_id1, slice_id2)
function img =	ibinterpolateLines>draw_2d_lines (img, snake)

Detailed Description

Interpolate lines between the slices.

Function Documentation

function img = ib_interpolateLines	(		img,
			max_pnts,
			lineWidth
	)

Interpolate lines between the slices.

One of two interpolation methods. The interpolation method can be selected in im_browser->File->Preferences.

Note

This method can interpolate only the not closed lines.

Parameters

img	-> binary image dataset, for example the Selection layer [1:height, 1:width, 1:z]
max_pnts	-> maximal number of points used for interpolation.
lineWidth	-> width of the line in pixels.

Return values

img	-> binary image dataset, for example the Selection layer [1:height, 1:width, 1:z]

See Also

ib_interpolateShapes

Referenced by menuSelectionInterpolate().

Here is the caller graph for this function:

function img = ibinterpolateLines>draw_2d_lines	(		img,
			snake
	)

function contour = ibinterpolateLines>interp_points	(		contour1,
			contour2,
			slice_id1,
			slice_id2
	)
