bitmap2amiraMesh.m File Reference

Convert bitmap matrix to Amira Mesh binary format. More...

Functions
function result =	bitmap2amiraMesh (filename, bitmap, img_info, options)
	Convert bitmap matrix to Amira Mesh binary format. More...

Detailed Description

Convert bitmap matrix to Amira Mesh binary format.

Function Documentation

function result = bitmap2amiraMesh	(		filename,
			bitmap,
			img_info,
			options
	)

Convert bitmap matrix to Amira Mesh binary format.

Parameters

filename	filename for Amira Mesh file
bitmap	a dataset, [1:height, 1:width, 1:colors, 1:no_stacks]
img_info	img_info containers.Map from im_browser.m
options	a structure with some optional parameters .overwrite - if 1 do not check whether file with provided filename already exists .showWaitbar - if 1 - show the wait bar, if 0 - do not show .colors - [optional] - a matrix of colors for multiple color channels, format: [color channel][Red Green Blue] in range from 0-1. Applicable to the HxMultiChannelField3 type of data saving.

Return values

result

result of the function run, 1 - success, 0 - fail

Required fields of options:

Referenced by menuFileSaveImageAs(), cropObjectsDlg>cropBtn_Callback(), and mibchopDatasetGui>chopBtn_Callback().

Here is the caller graph for this function:
